F-110

Flotation Implement Tyres (I-3)
* Strongly built nylon construction ensures long life.
* Improved pattern design ensures high load capacity and low rolling resistance which ensures a good grip on the surface.
* Improved compounding ensures maximum life.”

Send Enquery

Product information

Size (F-110)	Ply Rating	TT/TL	Rim REC (Inch)	Inflated ±2% Section Width In mm	Inflated ±2% Overall Diameter In mm	Static Load Radius (mm)	Rolling Circumference ±2.5% (mm)	Load capacity free rolling wheel 30km/h A6 Load Index	Load capacity free rolling wheel 30km/h MAX Load (kg)	Load capacity free rolling wheel 40km/h A8 Load Index	Load capacity free rolling wheel 40km/h Max Load (kg)	Inflated Pressure in KPA
400/60-15.5	8	TL	AG13	404	874	380	2561	138	2360	132	2000	320
400/60-15.5	12	TL	AG13	404	874	380	2561	145	2900	141	2575	380
400/60-15.5	14	TL	AG13	404	874	380	2561	149	3250	143	2725	490
400/60-15.5	16	TL	AG13	404	874	380	2561	153	3650	147	3075	550
400/60-15.5	18	TL	AG13	404	874	380	2561	155	3875	149	3250	600
500/50-17	14	TL	16	503	932	406	2750	155	3875	152	2800	380
500/50-17	16	TL	16	503	932	406	2750	158	4250	155	4250	420
500/50-17	18	TL	16	503	932	406	2750	160	4500	157	4500	480

Size (F-110)	Ply Rating	TT/TL	Rim REC(Inch)	Rim ALT (INCH)	Inflated ±2% Section Width In mm	Inflated ±2% Overall Diameter In mm	Static Load Radius (mm)	Rolling Circumference ±2.5% (mm)	Load capacity free rolling wheel 40km/h A8 Load Index	Load capacity free rolling wheel 40km/h MAX Load (kg)	Load capacity free rolling wheel 50km/h A8 Load Index	Load capacity free rolling wheel 50km/h Max Load (kg)	Load capacity Drive Wheel 40km/h A8 Load Index	Load capacity Drive Wheel 40km/h MAX Load (kg)	Load capacity Drive Wheel 50km/h A8 Load Index	Load capacity Drive Wheel 50km/h Max Load (kg)	Inflated Pressure in KPA
550/60-22.5	12	TL	AG16.0	–	550	1240	540	3750	160	4500	156	4000	148	3150	144	2800	210
550/60-22.5	16	TL	AG16.0	–	550	1240	540	3750	167	5450	163	4875	154	3750	150	3350	280
600/55-22.5*	12	TL	AG20.0	–	600	1230	540	3716	164	5000	160	4500	151	3450	148	3150	200
600/55-22.5*	16	TL	AG20.0	–	600	1230	540	3716	169	5800	166	5300	156	4000	153	3650	260
600/50-22.5*	12	TL	AG20.0		611	1172	508	3501	159	4375	156	4000	147	3075	144	2800	200
600/50-22.5*	16	TL	AG20.0		611	1172	508	3501	165	5150	161	4625	153	3650	149	3250	260
600/50-22.5*	18	TL	AG20.0		611	1172	508	3501	167	5450	163	4875	155	3875	151	3450	290
700/40-22.5*	12	TL	AG24.0		700	1175	510	3530	160	4500	157	4125	148	3150	144	2800	170
700/40-22.5*	16	TL	AG24.0		700	1175	510	3530	166	5300	162	4750	154	3750	150	3350	220
